KEY FEATURES
Unrivaled CREE LED Technology
Sophisticated Mono Crystalline Solar Panel
Complete Unit IP-65 Protected
Cyclone/Hurricane/Typhoon Weather Rating
Advanced LED Compensation Technology
Intelligent Battery Management System (IBMS)
Durable Construction & Quality Components
Pole Integrated Battery Pack KEY BENEFITS
Power to Run All Night
No External Cabling or Trenching Required.
Install Without Electrician
Extreme Weather Resistance
Impact Resistant & Vandal Proof
Safe Consistent Performance & Lifespan
Ultra Reliable Built to Last
Zero Maintenance System
Warranty Included
Fully Customer Endorsed
Smart City Ready PERFORMANCE
Designed to give all night operation up to 14 hours per night in all weather conditions at 5,610 Lumens MOUNTING HEIGHT
Maximum Height = 30 Ft.
Suggested Height = 23 Ft.TECHNICAL INFORMATION
LED
28 x USA made CREE XP-G led configured in 2 x 14 LED arrangement
TECHNICAL SPECIFICATIONS
24V DC operation – meaning NO need for electricians to install or repair this system
Color-coded quick release wiring system for simple installation no screwdrivers required
No photo sensor (day night switch) which is 90% of failures in street lights.
No electrical power needed, our street light is fully self sufficient for power up to 14 hours a day
High vandal resistance (heavy duty guard on back of solar panel, and poly-carbonate lens on light for high rock resistance)
GENERAL INFORMATION
30W CREE LED – 3900lm, Light efficiency <100lm/W
Zero Maintenance System
DIY Installation – Low Voltage – 24VDC
Light spacings AS1158.3.1 P3 = 20m / P4 = 50m
Cyclonic wind rated to region C (optional Region D)
5 Years Warranty (3 years battery / 10 years metal work)
VANDAL RESISTANCE
FLED – High strength Poly-carbonate + Aluminum
Solar Panel – 400W Impact resistant solar panel with stone guard
Battery Storage – 0.39″ plate steel with recessed security screws
Advanced LED Compensation Technology – Compensates for broken LED chips if damaged by impact
STEEL WORK + WEATHER RESISTANCE
IP65 with complete unit able to withstand full immersion from floods and still operate
IP68 waterproof connectors
Fully Galvanized 0.11″- 0.62″ thick steel, re-enforced metalwork w/stainless fixings
Ideal in high wind areas
Underground cage footings and certified cage as part of kit to Australian cyclone standards
All nuts, bolts washers, Serial number plate, installation manual & security key are supplied in durable transport kit
SOLAR PERFORMANCE
205W Mono-crystalline with toughened glass and re-enforced frame, tuned for optimum low light and winter performance
Pre-wired and assembled in Transport box for easy installation
BATTERY + CHARGING SYSTEM
Advanced charging system measures ambient and battery temperature and varies the charge current, increasing battery life expectancy by up to 4X even in desert or tropical environments
Over discharge, short circuit, reverse polarity protection
2 x Sealed high quality GEL AGM 120Ah batteries (240AH total) with waterproof connectors (*7-10 years expected life)
PERFORMANCE
Dusk till Dawn automatic operation
Designed to charge in overcast / rainy locations
Up to 14 hour a night operation in most weather conditions
Proven performance in tropical, desert, beachfront and wet locations
LED (60W-100W)
CREE USA made LED in 2 x 14 banks
Quick release waterproof IP-68 connector (no wiring required)
Roadway , floodlight or combination lenses available
Easily Adjustable LED angle to adjust light throw / spill light direction
Inbuilt LED driver in base of pole
CERTIFICATIONS
AS1158.3.1 P1-P12, AS60598 Australian Certified LED
AS1214, IEC61347,AS60598,AS1170, AS4600, AS4680,AS3600, AS4671
Location specific AS1158.3.1 certifications available
Typical spacing 40-50m, P11, P11b, P11c, P12
OVERALL DIMENSIONS
Total height 27.88 ft
LED height 26.24 ft on 3.93 ft outrigger
PROGRAM OPTIONS
Standard – Dusk till Dawn Auto On/OFF
Programmable ON_OFF 1-14 hours
+ 5-100% dimming
1-4 hours before Dusk ON auto sensing
5-100% dimming in any program modes
Many other program options available
