LED
28 x USA made CREE XP-G led configured in 2 x 14 LED arrangement
TECHNICAL INFORMATION
Integrated 50W N-Mono-crystalline solar panel
Integrated 32Ah LiFePo4 battery incorporating GFS-Advanced Cell Technology
CREE 2805Lm LED, PIR Motion sensor
OPERATION
Designed to give all night operation up to 14 hours per night in most weather conditions at 1402Lm****
Mounting height – 26 ft maximum height suggested height 23ft
LED
14 x USA made CREE XP-G led configured in 2 x 7 LED arrangement
2805lm total output
Bank 1 – 7 x LED 1402lm all night mode
Bank 2 – 7 x LED 1402lm Motion sensor trigger for 30 seconds
4000K CCT, 70 CRI 187lm/w
Dual LED driver technology for ultimate reliability
LENS
Sophisticated, indestructible poly-carbonate lens allows for precise evenly distributed directional illumination output.
Meets International lighting standards, less poles required for significantly more illumination
Type 3 Pathway / roadway 135º 85º (standard)
Type 5 Round Lens 110º (optional)
MOTION SENSOR
Advanced PIR Passive Infra Red with Repeat Trigger feature (stays on full power as long as heat source movement is detected)
Eliminates false triggering (trees, high winds and small rodents)
360º sensing range
20 feet detection range when mounted on 20ft Pole*
Vandal resistant design with optional PIR guard
SOLAR PANEL
USA made N-Mono-crystalline cells Military Grade 24% class leading efficiency
50W Maximum Power output – Most compact rectangular 50W solar panel on the market today
Advanced edge-less frame design at 7º angle prevents buildup of dirt and bird fouling
Optimum power at any solar orientation due to advanced Cell and controller technology
BATTERY
GFS designed (ACT) -advanced Cell Technology next generation LiFePO4 battery system
12.8v 32AH (409.6Wh)
54 hours continuous light output in all night mode
4.5 days backup power**
Integrated IBMS (intelligent battery management system) featuring short circuit, over temperature, over charge and over current protection
Cell Balancing technology with temperature compensation
SMART CONTROLLER
Monitors all vitals of the unit, including LED, Solar, battery, temperature
Manual dimming potentiometer to give prolonged light output in shaded environments
MPPT Charging with 99% tracking efficiency
IOT Ready smart city***
Flexible on /off programs
Auto /On /OFF set as default (on at dusk, off at dawn)
Real time clock for precise on /off times
Ability to program turn on hours, before sunrise
Multiple on/off programs per night
RS485 interface with hand programmer
HOUSING + PAINT
IP65 fully sealed fitting
Heavy duty cast aluminum housing
Marine grade USA made Tiger Coating
Primer coat and 2 x top coat ensuring ultimate weather resistance
Stainless steel 316 and 304 grade fixtures
OPERATING TEMPERATURE
-4ºF to 140ºF (-20ºC to 60ºC)
PRODUCT DIMENSIONS + WEIGHT
21.26″ x 21.26″ x 2.56″ – 37.47lbs
PACKING DIMENSIONS
24.41″L x 24.41″W x 6.69″D
WARRANTY
5 year warranty*****
SAIL AREA
(Horizontal sail area calculation) 1.233 sq. ft.
CERTIFICATIONS
Product and component certifications listed UL E349212 LED, UL1642
Battery, IEC62133CE/BIS, CE ISO9227-2017 Salt Spray, ISO12944 paint corrosion resistance, UL3135 Cabling, UL1598 Safety Luminaires, UL8750
LED Safety, UL1703, FCC Part 15 class B
Certified to meet ANSI/IES RP-8-14 and ANSI/IES RP-20-14 lighting standards
*Based on standard tests at 77ºF at 20ft mounting height in test conditions. Stealth lights mounted on higher poles will shorten the sensing range
**Days backup is calculated on a 12 hour night time operation @ 1,402 lumens
***When fitted with optional control system
****GFS does NOT guarantee lighting performance due to many factors outside of GFS control such as shading, dirt, bird fouling and excessive triggering, however based on test data from numerous installs across the world 14 hour a night operation has been achieved in typical installs
*****5 year on all components except battery (3 year) refer to specific warranty T&C’s document
